1270HWheeled Harvester
- Powerful, all-around harvester
- IBC as standard
- H7 boom with high lifting and slewing torque
- Easy service and maintenance
- Large selection of harvester heads
- Excellent visibility to the working area
Strong H7 boom
H7 is a strong boom with excellent performance. It features high lift and slew forces and a wide motion range. The centralized lubrication system makes H7 easy to maintain. Good visibility to the working area.
Gross lifting torque 217 kNm
Slewing torque 55 kNm
Intelligent Boom Control IBC as standard
Intelligent Boom Control (IBC) is a standard feature in all H Series harvesters. With IBC, boom control is precise, fast and easy because the operator can focus on controlling the boom tip rather than single boom joint movements.
Next-level cabin comfort
The rotating and levelling H cabin is standard in all H Series machines. The cabin rotates 220 degrees, which gives an excellent view to the working area. The climate control system, good storage space and better lights makes the operator’s working day more comfortable.
More stability with frame lock
The cylinder-operated frame lock makes our machines steady in all terrains and enables excellent stability while working with the boom sideways, offering the operator a large working area. Confident and stable working with the cylinder-operated, strong frame lock and maximized stability with the optional active frame lock.
Features
Expand AllCollapse All
TimberMatic H control system
The TimberMatic™ H control system with the integrated TimberMatic Maps helps the operator achieve superior performance and productivity.
TimberMatic H automation with the programmable button joysticks offers ease of use and improved ergonomics. The interface is simple, and the H automation system creates consistent user experience across all forestry products. The visualization includes options for night and daylight view. The on-screen view only shows the info relevant to the situation.
- Site starting made easy with TimberManager
- Data flow between machine and TimberManager: StanForD files, reports, worktime etc.
- Daylight and low light themes
- Tree species and timber assortments visualized with different colors.
- Availability of operator-, site- and machine-specific information (e.g. performance & efficiency metrics).
Intelligent Boom Control IBC
IBC is a standard feature in all H Series harvesters.
The harvester’s IBC system has been adjusted precisely to the work cycle; the trajectory and functioning of the boom changes depending on, e.g., whether the harvester head is empty or if it is holding a tree.
IBC improves work ergonomics and guides the operator in the correct use of the boom extension. Boom operation becomes softer and smoother, thereby reducing stress on the entire boom.
The boom tip automatically follows the desired trajectory. Choosing hill mode makes the trajectory better suited for working on a slope.
The harvester head is automatically driven to the optimal harvesting height. The system guides the use of the extension intelligently during different work phases and reduces stress on the boom.
Intelligent control of the boom turning improves the control of movements also in long reaches. The boom is easy to use and precise to operate.
IBC 3.0 is available for the 1270H.
DRAG TO ROTATE
Harvester heads
John Deere harvester heads are known for their productivity, reliability and especially accuracy. The harvester heads have efficient feeding and delimbing.
