Drivetrain Components

Drivetrain Components

Axles

1200 series axle

1200 Series

Axle
  • Peak output torque: 35,000 Nm (310,000 in-lb)
  • Peak Vertical Load: 240,000 N (54,000 lb)
  • Reduction ratios: 4.333:1 - 33.429:1
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide
1400 series axle

1400 Series

Axle
  • Peak output torque: 47,400 Nm (420,000 in-lb)
  • Peak Vertical Load: 300,000 N (67,000 lb)
  • Reduction ratios: 16.208:1 - 32.914:1
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide
1400 series axle SWEDA

1400 Series SWEDA

Axle
  • Peak output torque: 47,400 Nm (42,000 in-lb)
  • Peak Vertical Load: 300,000 N (67,000 lb)
  • Reduction ratios: 27.927:1 - 30.578:1
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

Series 1600

Axle
  • Peak output torque: 67,700 Nm (600,000 in-lb)
  • Peak Vertical Load: 395,000 N (88,000 lb)
  • Reduction ratios: 22.5:1
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

Planetary Gear Drives

planetary gear drive F9R

F9

Planetary Gear Drive
  • Drive type: Speed reducer
  • Output torque: 12,880 Nm (9500 lb-ft)
  • Max input speed: 2800 rpm
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

F12

Planetary Gear Drive
  • Drive type: Speed reducer
  • Output torque: 16,948 Nm (12,500 lb-ft)
  • Max input speed: 2800 rpm
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

F25

Planetary Gear Drive
  • Drive type: speed reducer
  • Output torque: 33,895 Nm (25,000 lb-ft)
  • Max input speed: 2800 rpm
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

Transmissions

2000

Powershift Transmission
  • Max input power: 168 kW (225 hp)
  • Max input no load speed: 3000 rpm
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

DF150

Powershift Transmission
  • Max input power: 112 kW (150 hp)
  • Max input no load speed: 3000 rpm
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

DF250

Powershift Transmission
  • Max input power: 186 kW (250 hp)
  • Max input no load speed: 2600 rpm
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

DFXRXA

PTO Transmission
  • Max input power: 224 kW (300 hp)
  • Max input no load speed: 3000 rpm
Contact a Distributor
Drivetrain Selection Guide

HMD12700

Hydrostatic Transmission
  • Max input power: 104 kW (140 hp)
  • Max input torque: 407 Nm (300 lb-ft)
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

HMD18000

Hydrostatic Transmission
  • Max input power: 149 kW (200 hp)
  • Max input torque: 949 Nm (700 lb-ft)
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

HMD23000

Transmission
  • Max input power: 75 kW (100 hp)
  • Max input torque: 271 Nm (200 lb-ft)
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

HMD33000

Hydrostatic Transmission
  • Max input power: 101 kW (135 hp)
  • Max input torque: 407 Nm (300 lb-ft)
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide

HS17000 HMD

Transmission
  • Max input power: 93 kW (125 hp)
  • Max input torque: 1017 Nm (750 lb-ft)
Download Spec Sheet
Contact a Distributor
Drivetrain Selection Guide
